Expanded Bore & Fluid Dynamics Optimization: Optimized internally for DN65 to DN200 pipelines. The spacious and rounded geometry of the internal flow chamber completely minimizes dead corners and turbulence, lowering the flow resistance coefficient and yielding a flow capacity (Kv value) that far surpasses standard solenoid valves.
Low Power Consumption & Zero Heat Dispersal: Traditional solenoid valves experience extreme coil heating during prolonged energized opening, often leading to coil burnout. The YSG series leverages pulse control, energizing only at the fraction of a second during switching actions (typically requiring a pulse width of only 30-50 ms). The coil remains completely unenergized for the vast majority of its operation, eliminating thermal buildup and boosting electrical safety.
Superior Low-Pressure Bootstrap Capability: Addressing the industrial drawback where large-bore valves require massive pressure differentials to open, this series optimizes the area ratio of the diaphragm/disc, smoothly unlocking full-capacity blasting or transport under an ultra-low pressure of just 0.3 bar.
Application-Specific Material Configurations: The JF Series utilizes SS304 Stainless Steel, providing not only corrosion resistance but also meeting strict hygiene standards for pharmaceutical, food processing, or light-chemical water systems. The CF Series uses heavy-duty Cast Iron, delivering massive mechanical robustness and exceptional cost-efficiency, making it highly suitable for environmental dust bagging networks, industrial circulating water, and agricultural irrigation networks.
All-Weather Wide Thermal Resilience: The valve body and elastomeric seals undergo rigorous thermal cycle testing from -20 ℃ to 65 ℃. The sealing compounds sustain perfect flexibility and cracking resistance at low temperatures, successfully preventing freezing-induced fractures or nocturnal leakage in outdoor installations.
