Features
1.Zero-Leakage Sealing Structure: Utilizes a unique interference fit design between the plunger and elastic sealing rings. By adjusting the pre-tightening force of the middle flange bolts, the sealing rings are radially compressed, forming a reliable radial sealing pair on the outer surface of the plunger. This completely replaces the traditional flat sealing structure of stop valves, achieving excellent zero-leakage sealing performance, particularly suitable for steam, oil, and working conditions with strict leakage control requirements.
2.Long-Life Sealing Components: The sealing rings are made of flexible graphite, PTFE, and high-elasticity composite materials, offering excellent high-temperature stability, self-lubrication, and resilience. They maintain sealing performance without degradation during long-term frequent operation. The plunger is precision-polished to a high surface finish, forming a beneficial friction pair with the sealing rings, significantly extending the valve's service life.
3.Adaptability to Harsh Conditions: The plunger is made of stainless steel, providing good corrosion resistance and anti-erosion capability. Sealing ring materials can be flexibly selected based on working conditions—flexible graphite for high-temperature steam, PTFE for highly corrosive media—ensuring long-term stable operation of the valve in high-temperature, high-pressure, and corrosive environments.
4.Self-Cleaning and Anti-Seizing: The radial sealing structure between the plunger and sealing rings creates a wiping action during opening and closing, automatically removing impurities and scale accumulated on the plunger surface, preventing particle seizing on the sealing surface. Additionally, the reciprocating vertical motion of the plunger ensures uniform wear of the sealing rings, avoiding sealing failure caused by localized excessive wear.
5.Easy Operation and Quick Opening/Closing: The plunger has a short vertical lifting stroke, significantly reducing the number of operating turns compared to traditional stop valves. The precise valve stem guide structure ensures smooth movement and low operating torque, making it suitable for applications requiring frequent operation. It can be equipped with handwheels, electric actuators, or pneumatic actuators to meet various automation control requirements.
6.Compact Structure and Convenient Maintenance: Features a flanged connection conforming to national standards for easy installation. The sealing rings are independent, replaceable components. During maintenance, the entire valve does not need disassembly; simply opening the bonnet allows for replacement of the sealing components, resulting in low maintenance costs and minimal downtime. The valve body flow path is smoothly designed for low medium flow resistance, offering significant energy-saving effects.
7.Wide Applicability: Suitable for water, steam, oil, gases, and various corrosive media. Widely used in process pipelines in petroleum, chemical, electric power, metallurgy, pharmaceutical, and heating systems, especially suitable for steam pipelines and thermal oil systems requiring frequent operation and stringent sealing performance. It is an ideal shut-off and control element in modern industrial piping systems.
