The ZCS series water and gas solenoid valve is a common execution element in industrial process automation control systems. This valve is primarily used for the automatic opening or shut-off of low-to-medium pressure fluid media such as water, air, oil, hot water, and general gases. Utilizing a direct-acting or pilot-operated piston structure, the valve is actuated by electromagnetic force generated by the coil to achieve rapid flow control. Due to its wide range of sizes, excellent sealing reliability, and media adaptability, the ZCS series is extensively applied in agricultural irrigation, environmental water treatment, food machinery, cleaning equipment, and various industrial piping automation systems.

Product Image of ZCS Solenoid Valve for Water and Gas

1.Rapid switching response:Driven by high-efficiency electromagnetic induction, opening and closing actions are completed within milliseconds, enabling high-frequency rapid control of fluids.
2.Extensive size and specification range:Covers sizes from DN0.5 micro-control to DN100 high-flow capacity, flexibly meeting requirements from precision lab dosing to large industrial pipelines.
3.Excellent material compatibility:Body available in cast steel or stainless steel. Seals use NBR, FKM, or PTFE to ensure long-term stability under different temperature and pressure environments up to 120°C.
4.Low power and low temperature rise:The coil features an optimized magnetic circuit design with minimal energy consumption and low heat generation. High protection ratings allow for safe operation in humid environments.
5.Smooth flow path and high capacity:The streamlined internal cavity minimizes flow resistance and pressure drop. It maintains efficient control while minimizing impact on system head loss.
6.Diverse connection standards:Available in threaded (NPT/G) and flanged types. The compact layout facilitates integrated installation inside equipment with limited space.
7.Reliable sealing performance:Precision-ground seats combined with resilient sealing materials ensure zero leakage within rated pressures, effectively reducing media loss and energy consumption.
8.Easy maintenance and long life:Simple structure with few wearing parts treated for wear resistance. Modular coil and body assembly allow for internal cleaning without removing the valve from the line.

Structural Drawing of ZCS Solenoid Valve for Water and Gas

List of Component Names and Materials

Performance Specification Sheet

Standard requirements for external dimensions

1. The structural length of the valve shall comply with the standard of GB/T12221

2. Connecting flanges according to GB/T17241.6 standard

Outline dimension table（Unit：mm）
