1. Corrugated plate flame arrestor element: Multiple layers of stainless steel corrugated strip and flat strip are alternately wound to form uniform triangular or rectangular narrow passages, providing a very short flame quenching distance for stable and reliable flame arresting performance.
2. Bidirectional flame arresting: Can block flame propagation from either the tank side or the atmosphere side, suitable for installation on both inlet and outlet of breather valves.
3. Large flow area, low pressure drop: High porosity (≥90%) of the corrugated channels minimizes gas flow resistance without affecting normal tank breathing capacity.
4. High temperature resistance: Stainless steel construction withstands short-term high-temperature flame impact without deformation or sintering.
5. Strong corrosion resistance: Flame arrestor element and housing available in 304, 316L stainless steel or carbon steel (with anti-corrosion coating) for various corrosive media and outdoor environments.
6. Compact structure, easy installation: Flange connections match standard breather valve and piping interfaces; can be installed horizontally or vertically; easy to disassemble for maintenance.
7. Code compliant: Designed and manufactured according to GB 5908, ISO 16852 and other standards, certified by authorized testing agencies.
8. Easy maintenance: Flame arrestor element can be extracted from the housing for periodic cleaning of carbon deposits or impurities and then reinstalled, eliminating the need for complete replacement.
