TD342X Worm Gear Operated Flow Control Butterfly Valve

Model：TD342X-10Q/TD342X-16Q/TD342X-10C/TD342X-16C/TD342X-25C
Specification：DN200-DN1200
Temperature：≤80℃
Medium：Water and water-like media

Pressure：PN10~PN25
Connection method：flange
Driving method：Worm Gear
Material：Ductile Iron, Cast Steel

Consult now

Add QR code to serve you!

TD342X Worm Gear Operated Flow Control Butterfly ValveOverview

The TD342X Worm Gear Control Butterfly Valve is a flange butterfly valve featuring a turbine worm drive mechanism and dual eccentric design. By precisely rotating the butterfly plate within a 0° to 90° range, it enables continuous flow regulation and reliable shut-off of pipeline media. Balancing operational flexibility with airtight sealing, this valve is widely used in water treatment plants, power plants, municipal water supply systems, chemical facilities, and industrial circulating water systems requiring precise flow control.

Product Image:TD342X Worm Gear Operated Flow Control Butterfly Valve

TD342X Worm Gear Operated Flow Control Butterfly ValveCharacteristic

1. The system features precise regulation and effortless operation. Its turbine worm gear mechanism delivers a high transmission ratio and substantial torque output, enabling effortless flow control under large-diameter or high-pressure-difference conditions. The design also ensures accurate butterfly plate opening control with self-locking functionality.

2. Double eccentric design ensures reliable sealing: The dual eccentric configuration (with valve stem axis offset from both butterfly plate center and valve body center) enables the butterfly plate to disengage from the valve seat instantly during opening, significantly reducing friction and extending seal durability. During closing, the progressively tighter sealing effect ensures bidirectional sealing reliability.

3. Low flow resistance and energy-efficient: The butterfly plate features a frame-type design with high structural strength. When fully open, it minimizes obstruction to the flow channel, resulting in low flow resistance and reduced energy consumption in pipeline systems.

4. Easy installation and maintenance: Compact design with lightweight construction. The valve supports multiple installation orientations (horizontal/vertical) and is not restricted by fluid flow direction. Wear-prone components like sealing rings are replaceable, eliminating the need to disassemble the valve body during maintenance and simplifying the process.

5. Versatile material options and adaptable performance: Key components like valve bodies and butterfly plates can be manufactured from cast iron, cast steel, or stainless steel, tailored to specific operational requirements. The sealing assembly typically combines stainless steel with nitrile rubber, ensuring compatibility with water, air, oil-based fluids, and mildly corrosive media.

TD342X Worm Gear Operated Flow Control Butterfly Valvestructure principle

Structural Drawing:TD342X Worm Gear Operated Flow Control Butterfly Valve

List of Component Names and Materials

List of Component Names and Materials
body	WCB、QT450-10、HT200、HT250
plate	WCB、QT450-10、HT200、HT250
shaft	2Cr13
sealing ring	Nitrile oil resistant rubber
packing	Flexible graphite

TD342X Worm Gear Operated Flow Control Butterfly Valvetechnology parameter

Performance Specification Sheet

Performance Specification Sheet
Nominal Pressure	1.0	1.6	2.5	MPa
Strength test pressure	1.5	2.4	3.8
Sealing test pressure	1.1	1.76	2.8
Applicable Temperature	≤80			℃

TD342X Worm Gear Operated Flow Control Butterfly Valvestandard size

Standard requirements for external dimensions

1. The structural length of the valve shall comply with the standard of GB/T12221

2. Connecting flanges according to GB/T17241.6 standard

Outline Drawing:TD342X Worm Gear Operated Flow Control Butterfly Valve

Outline dimension table

DN	Key dimensions					Flange size and bolt hole size
	L	H	H1	A	B	0.6Mpa				1.0Mpa				1.6Mpa
	L	H	H1	A	B	d	d1	d2	n-d	d	d1	d2	n-d	d	d1	d2	n-d
50	108	82.5	306	80	80	140	110	88	4-14	185	125	99	4-18	165	125	99	4-18
65	112	92.5	321	80	80	160	130	108	4-14	185	145	118	4-18	185	145	118	4-18
80	114	100	346	80	80	190	150	124	4-18	200	160	132	8-18	200	160	132	8-18
100	127	110	387	95	95	210	170	144	4-18	220	180	156	8-18	220	180	156	8-18
125	140	125	411	95	95	240	20	174	8-18	250	210	184	8-18	250	210	184	8-18
150	140	142.5	447	95	95	265	225	199	8-18	285	240	211	8-22	285	240	211	8-22
200	152	170	607	190	308	320	280	254	8-18	340	295	266	8-22	340	295	266	12-22
250	165	192.5	688	190	308	375	335	309	12-18	395	350	319	12-22	405	355	319	12-26
300	178	222.5	742	190	308	440	395	363	12-22	445	400	370	12-22	460	410	370	12-26
350	190	252.5	797	190	308	490	445	413	12-22	505	460	429	16-22	520	470	429	16-26
400	216	282.5	930	270	466	540	495	463	16-22	565	515	480	16-26	580	525	480	16-30
450	222	307.5	975	270	466	595	550	518	16-22	615	565	530	20-26	640	585	548	20-30
500	229	335	1065	270	466	645	600	568	20-22	670	620	582	20-26	715	650	609	20-33
600	267	390	1225	457	625	755	705	667	20-26	780	725	682	20-30	840	770	720	20-36
700	292	447.5	1343	457	625	860	810	772	24-26	895	840	794	24-30	910	840	794	24-36
800	318	507.5	1436	457	625	975	920	878	24-30	1015	950	901	24-33	1025	950	901	24-39
900	330	557.5	1616	598	853	1075	1020	978	24-30	1115	1050	1001	28-33	1125	1050	1001	28-39
1000	410	615	1711	598	853	1175	1120	1078	28-30	1230	1160	1112	28-36	1255	1170	1112	28-42
1200	470	727.5	1971	598	853	1405	1340	1295	32-33	1455	1380	1328	32-39	1485	1390	1328	32-48
1400	530	837.5	2218	860	1345	1630	1560	1510	36-36	1675	1590	1530	36-42	1685	1590	1530	36-48
1600	600	957.5	2578	860	1345	1830	1760	1710	40-36	1915	1820	1750	40-48	1930	1820	1750	40-56
1800	670	1057.5	2689	860	1345	2045	1970	1918	44-39	2115	2020	1950	44-48	2130	2020	1950	44-56
2000	760	1162.5	3022	952	1592	2265	2180	2125	48-42	2325	2230	2150	48-48	2345	2230	2150	48-62
