Characteristic
1. Forged steel valve body, high strength
The valve body is forged from high-quality forged steel (such as A105, F304, F316), with a dense structure, no casting defects, high mechanical strength, and good impact resistance, suitable for high pressure and fatigue conditions.
2. Clear stem structure, intuitive valve position
The valve stem rises and falls with the gate, and the valve opening can be directly determined by observing the height of the valve stem extension, which is convenient for operation and maintenance.
3. Alloy steel hard seal ("H" type)
The sealing surface of the valve disc and seat is welded with hard alloy (such as 13Cr, Stellite), which has high hardness, wear resistance, erosion resistance, high temperature resistance, reliable sealing, and long service life.
4. Flange connection, stable and reliable
Using standard flange connections (such as RF, RTJ), the connection strength is high, the sealing performance is good, and it is easy to install and disassemble.
5. Suitable for high temperature and high pressure working conditions
The overall structure and material selection make it suitable for higher working pressures (such as PN16-PN100) and temperatures (-29 ℃~425 ℃), with stable performance.
6 full bore design, low flow resistance
Adopting a full bore flow channel, the medium has low flow resistance and pressure loss, making it suitable for systems with pressure drop requirements
