1. Specially designed for sampling
Designed for the special requirements of sampling operations, it can achieve fixed-point, quantitative, and safe collection of process media. The sampling port design is reasonable and easy to connect to the sampling container.
2. Diaphragm type sealing structure
Adopting diaphragm sealing, the valve stem is isolated from the medium, with no risk of leakage, making it particularly suitable for sampling toxic, harmful, flammable, explosive, and corrosive media.
3. Hard or soft seals are optional
The sealing surface can be selected from metal hard seals or soft seals such as polytetrafluoroethylene (PTFE) ("F" type) to meet different medium characteristics and sealing grade requirements.
4. Accurate sampling and easy operation
The opening degree of the valve disc can be precisely controlled through the handwheel, achieving medium collection with small flow rate and controllable flow rate. The operation is easy and the sampling repeatability is good.
5. Compact structure and easy installation
Compact in size, usually using threaded connections (such as NPT, G threads), can be directly installed on pipelines or equipment sampling ports, occupying little space.
6. Flexible material selection
The valve body material can be selected from stainless steel (304/316), carbon steel, etc., to meet the corrosion requirements of different media. The internal parts can be hardened to improve wear resistance.
7. Safe and reliable, prevent leakage
The sealing structure design is rigorous, and it is tightly closed after sampling to prevent medium leakage and ensure the safety of operators and environmental cleanliness.
