Efficient Pilot-Operated Drive: By utilizing the pipeline medium's pressure as the driving force, the mechanical load on the electromagnetic coil is vastly minimized. Within the 0.3 to 8 Bar range, it provides swift, highly sensitive on/off actuation alongside low energy consumption, substantially extending coil durability.
High-Strength PA66 Body: The premium reinforced Polyamide 66 body yields outstanding mechanical strength, wear resistance, and water-hammer endurance. It maintains physical and structural integrity within a fluid/ambient temperature range of -10 to 50 ℃, ensuring rust-free and contamination-free operations.
Full Large-Bore Coverage: Specifications span from DN15 to DN80 (1/2" to 3"), perfectly accommodating high-flow requirements from standard branch pipes to main transmission pipelines.
Versatile International Threads: Both G and NPT thread connection variants are provided, fully aligning with domestic and international industrial market standards.
Hydrodynamically Streamlined Flow: The internal geometry features a large-orifice, low-resistance design optimized for large diameters, ensuring optimal flow capacity (high Cv rating) while diminishing localized fluid turbulence and pressure drops.
Industrial-Grade Protection: Equipped with an IP65-rated industrial coil that yields exceptional dustproof and waterproof capabilities, guaranteeing continuous and safe performance even in damp irrigation pump stations or harsh industrial workshops.
